Dispersion Kneader Landmark’s experience and continual feedback from customers in kneading technology has resulted the most efficient and high quality processing of raw material in various formulation & application.
- Hydraulically Operated or Pneumatically operated piston to give force to the pressure lid.
- Various electrical & Mechanical safety interlocks to avoid any accident to the equipment
or operator
- Heavy Duty Gear Box from reputed manufacturer of the country
- All rotating gears are duly Hardened & ground for longer life and least noise.
- Screw driven with brake Tilting unit for highest degree of Tilt upto 145 degree, which enables fastest and easy discharge
of the kneaded material
- Precisely placed temperature sensor to give more accurate temperature of the mixed/processed material
- Excellent rotor blade design, angle and precise clearance of the chamber gives best
quality processing in optimum time duration
- Cooling provision in Rotors, Chamber,
and pressure lid gives you the perfect chemistry to be used for processing, resulting
best quality processing for Heat Sensitive material and easy discharge of the mixed lump
from the chamber.
- Highest available quality of Hard Chrome Plating to all internal
parts of the mixing chamber.
- Electric control cabinet to operate the machine is
equipped with Highest Quality , perfect selection of the switch gears, Timers and Temperature
sensor and controller to give smooth operation for longer years.
- AC variable
drive for main motor is optional and suggested for the energy saving and longer life
of the prime movers in the machine
- Automatic or Manual lubrication system installed
for all moving parts to give smooth operation
- Best quality and innovated sealing
system gives more than 95% saving in leakage from the Rotors and dust coming out in the
ambient – resulted in minimizing the wastage and air pollution
- Multiple feeding
options can be offer as per customer convenience – Front feeding, back feeding, and top
feeding.
- All hardware used are from leading international manufacturer
Models Available: | |||
---|---|---|---|
Size | Standard Motor Capacity | Batch Size | |
Lab Size ( 1/3/5 Ltr) | 3/5/7.5 HP | 1.2 to 10 Kg | |
20 Ltr | 25HP – 40HP | 15 to 25 Kg | |
25/30 Ltr | 40HP – 60HP | 25 to 50 Kg | |
40 Ltr | 50HP – 75HP | 50 to 80 Kg | |
55 Ltr | 75HP – 100HP | 60 to 110 Kg | |
75 Ltr | 75HP – 125HP | 90 to 150 Kg | |
100 Ltr | 100HP – 150HP | 100 to 200 Kg | |
125 Ltr | 125HP – 180HP | 125 to 250 Kg | |
150 Ltr | 150HP – 220HP | 150 to 300 Kg | |
200 Ltr | 220HP – 300HP | 180 to 400 Kg |
